As part of the Digital Transition Series organised by CITA, Michael Earley and Liam Farrelly from Scott Tallon Walker Architects will be presenting on BIM in Education using the Trinity College Business School as a case study.
The presentation will be opened by David Browne, President RIAI and Barry Lowry, Government Chief Information Officer will speak about digital strategy and the National BIM Council Roadmap.
Date: Thursday 1st March – 7:30am to 10:30am.
Venue: Royal College of Physicians, No. 6 Kildare Street Dublin 2.
Agenda
08.00-08.10 Opening Address – David Bowne, President RIAI
08.10-08.30 Government Chief Information Officer, Barry Lowry
Case Study: BIM in Education – Trinity Business School
08:30-08.35 Michael Earley – Scott Tallon Walker Architects
08.35-08.50 Liam Farrelly – Scott Tallon Walker Architects
08.50-09.05 Adrian Ryan – Arup
09.05-09.20 Celine O’Connor – JJ Rhatigan and Company
09.20-09.30 Q&A
09.30-10.20 Panel Discussion on Commitment to NBC Roadmap
About Trinity College
Since its foundation four centuries ago, Trinity College Dublin has held rank as one of the world’s great universities. It is ranked 88th in the world, 22nd in Europe, combining advanced research and scholarship with an educational environment that values the whole student experience.
Invitation to Tender for Design Team
In August 2013, the governance board of Trinity College Dublin included a vision statement for a new Business School in the invitation to tender for design team members circulated via the Irish Public Procurement Service. This document included some important preambles for design teams which mirrored significant challenges that were happening in the construction industry such as global recession and the significant progression in technology which was and continues to disrupt businesses. The following are some important extracts:
Change
“The world is witness to a wave of transformative thinking: sweeping up conventions and rules, changing the way we work, how we interact, how we do business. This revolution spearheaded by unprecedented opportunities in research, market sharing, information access, cloud technology, product development and instant, unfettered communication is irreversible. It is transforming strategic management from the smallest start-up to the corporate giant. Impacts on how markets develop, thrive, and exchange knowledge or expertise are deep. Progress is inevitable.”
Recession
“The global recession, meanwhile, is driving a radical, reflective revisioning of business practice and methodology, abolishing the obsolete. New thinkers rake over the ashes of assumption seeking embers to spark a flicker flame of economic recovery, a crank to start a level shift in momentum. The Time for Change is Now.”
Managing Change
“But change can be impetuous. It can lose sight of traditions, enduring wisdom and age old cultural nuance of immeasurable value. This can have long-lasting effects on security, stability and identity. Culture, arts, social science, the humanities must stitch in, to bring an evolutionary refinement to the galloping pace of technology. Change must be managed consciously, carefully with insight and discipline.”
Invitation to Tender for Design Team – Level 2 BIM
The Invitation to tender required the Project Team to develop the preferred design to a Level 2 maturity Building Information Model (BIM) to allow the procurement of a Construction Contractor (i.e. managed 3D environment held in separate discipline ‘BIM’ models and tools with attached data. The architect as lead designer was required to prepare a project strategy or plan that provides for information sharing between all key design/construction disciplines via BIM, including exchange formats and procedures. Key requirements included:
- BIM to be used for client “virtual walk through” at various stages of design.
- BIM to be utilised to achieve optimum Energy performance for design options
- Building information to be recorded within COBie parameters for handover to client
It was exciting to see that Trinity College Dublin were taking a lead by procuring a project to Level 2 BIM standards. Like the aspirations for the development of the new Business School, the advancement of technology and new processes to manage design brought challenges which required strategy and careful management. The design team combined a knowledge of BIM software systems from graduates, BIM management skills gained from working on projects in the UK during the lean years and the experience of project architects and engineers who have been involved in similar projects.
The Site
Trinity Business School is being located on a 0.518 ha site approximately, within the campus of Trinity College Dublin, Dublin 2. The site is principally bounded by Pearse Street to the north; the existing railway line to the east; existing structures on Pearse Street to the west and the Trinity College campus to the south. The site also includes Nos. 183-188 Pearse Street (incl.), which are Protected Structures, which will be refurbished as a cafe and student accommodation with related ancillary uses. The development includes the demolition of the existing Sports Hall (Luce Hall) previously designed by Scott Tallon Walker Architects in the 1970s, the maintenance workshops and first floor WCs to the rear of Nos. 183-188 Pearse Street.
The Building
The development consists of a business school; innovation and entrepreneurship hub; auditorium; cafe and student accommodation with ancillary administration, staff and student uses. The proposed new building comprises six floors of lecture/office accommodation over two basement levels linked to Nos. 183-188 Pearse Street. The development also includes the refurbishment, including internal revisions, of Nos. 183-188 Pearse Street, which will be extended at the rear ground floor level to provide cafe use with student accommodation at first and second floor levels.
Entrances from Pearse Street and the campus are at ground floor level and give access to an atrium space which includes an Exhibition Area, access to a lecture theatre, access to the upper level of the 600-person auditorium, general circulation and informal meeting and gathering space. Stairs and passenger lifts give access to all lower and upper floors. The 600 seat Auditorium can accommodate both large and small audiences for events such as the welcoming of new students, major award ceremonies, lectures, graduation events and conference plenary sessions. It is capable of being used in a number of modes: entirely flat floor, raked and flat floor, or subdivided into two separate 300 seat spaces, one raked and one flat.
Survey
In February 2014, Scott Tallon Walker, Arup and IN2 prepared a specification for procurement of a survey which included a Point Cloud Survey for the protected structures, and the adjacent buildings. The document set-out very prescriptive requirements for the information to be delivered which included a Full cartographical two dimensional (2D) topographical survey, Point Cloud Survey and Revit models to varying levels of detail. The contextual Revit models Coastway Surveys who were the successful bidder have been very useful for such as constrained and historic site.
Planning and Regulatory Compliance
A Planning Application was submitted in June 2015 and permission was granted in September 2015. Fire Safety Certificate and Disability Access Certificate applications were lodged in in September 2015.
Invitation to Tender for the Construction Team
In January 2016, Turner & Townsend prepared the construction tender documentation which included documentation from Trinity College Dublin and the Design Team. Included with this tender documentation were comprehensive and updated Employers Information Requirements (EIR) and Supply Chain Capability Summary (SCCS) documents, prepared by TCD’s BIM Manager, and an Asset Information Requirements (AIR) document provided by Scott Tallon Walker and agreed with TCD which captured the requirements for all asset information in the model to be provided by the contracting team.
Tender documents for the main contract and separate Mechanical & Electrical contracts were issued in March 2016. As this was TCD’s first Level 2 maturity Building Information Model (BIM) capital project, the EIR and AIR documents were composed with the vision of utilising these on all future capital projects which would be procured using Level 2 BIM. The assessment of BIM Execution Plans (BEPs) was undertaken by TCD’s BIM Manager.
Construction Team
Enabling works which included civil works and a temporary electrical substation was awarded to BAM.
JJ Rhatigan and Company were awarded the main contract to construct the Business School in June 2016. T Bourke and Company were awarded the Mechanical Contract with the Designer Group being successful with the Electrical Contract.
Key Statistics:
- Site Area: 5,200 m2
- Gross Internal Area: 14,155 m2 including protected structures
- Contract / Delivery Type: Irish Government Public Works Contract – PWC-CF1 v2.0 Jan 2016.
- BIM: Level 2 BIM in accordance with PAS1192-2:2013
- Sustainability: NZEB, BER A2
Accommodation:
- The School of Business
- Innovation and Entrepreneurship Hub
- Auditorium
- Restaurants
- Pearse Street Terrace Refurbishment (Protected Structures)
Client Team:
- Director of Estates & Facilities: Paul Mangan
- Head of Capital Projects: Greg Power
- BIM Manager: Peter McDonnell
- Project Manager: Tom Armstrong
Design Team:
- Architects: Scott Tallon Walker Architects
- Structural/ Civil Engineer: Arup
- Façade Engineer: Arup
- Mechanical & Electrical Engineer: IN2
- Project Manager: Turner & Townsend
- Quantity Surveyor: Turner & Townsend
- PSDP: Turner & Townsend
- Fire Engineer: Michael Slattery and Associates
- Acoustics: AWN Consulting
- Sustainability: IN2
- Planning Consultant: Tom Philips and Associates
- Conservation Architect: David Slattery Conservation Architects
- BCAR Consultant: Procert
- Landscape Architect: Mitchell & Associates
- Catering Design: QA Design
Construction Team:
- Enabling Works: BAM
- Main Contractor: JJ Rhatigan and Company
- Mechanical Services Contractor: T Bourke
- Electrical Services Contractor: Designer Group
